Make a Stained Glass Beehive Ornament -Part 2

In this part of the tutorial we continue making the beehive ornaments.



To cut a piece of glass you can't see through you extend the template lines like you see here. I extended the lines out from that hexagon shape.



Now you can place opaque pieces of glass on the template and use those extended lines for the ruler.



Then I used a table top diamond grinder to clean all the edges and to do some shaping. This is optional. You can do stained glass without a grinder.



Ok, all the glass pieces are cut. The flowers look good! Let's solder these glass pieces together.

Next we use something called copper foil. It is copper tape with an adhesive on one side. We wrap it all the way around the edges of all the pieces.



Copper foil



Then use a tool to burnish all the foil -pressing it onto the edges and the flat of the glass. This burnishing adheres it securely to the glass -both the edges and the surfaces.



ok, everything is foiled.



Let's continue with the tutorial and do the soldering.






Gryphette Diamond Grinder -

Sold in 110V. The Gryphette offers the best value in a glass grinder today. The small enclosure houses a surprisingly powerful DC motor. Even when using 1" diamond bits, it is virtually impossible to stall the motor. The Gryphette is the perfect grinder for the occasional glass artist, student or classroom. The very low cost and convenient size will be appreciated by everyone who does not require the features of a larger grinder. Motor: 0.67 amp. Motor speed: 3000 rpm. Worksurface: 6.75" by 6.75". Base: 7.75" by 7.75". Base Height: 6.25" Weight: 6 lbs. Water Feed: Sponge. Warranty: 5 years. Shaft Diameter: 5/16"
